POWERHOUSE 20KVA Electric Automatic Voltage Regulator Servo Motor Control 20,000VA Power Supply PH-SVC-20KVA • PHE

BUILDMATE Powerhouse 20KVA Electric Automatic Voltage Regulator Servo Motor Control 20,000VA Power Supply PH-SVC-20KVA • PHE

SPECIFICATIONS:
►Model: PH-SVC-20KVA
►Range of Input Voltage: 160~250V or 70~130V
►Output Voltage: 230V or 110V
►Accuracy of Voltage Stabilization: 4%
►Over-Voltage Protection Value: Phase Voltage 257 + 4V
►Under-Voltage Protection Value: Phase Voltage 195 + 4V
►Frequency: 50Hz/60Hz
►Waveform Distortion: No additional wave distortion
►Load Power Factor: 0.8
►Efficiency: 90%
►Adjustable Time: <1.5s (when input voltage has a change of 10%)
►Delay Time:
-- Long time delay: 5 + 2mins; Short time delay: 5 + 2s
-- Usually, under-voltage protection is not provided, but it can be set at request
►Ingress Protection of Enclosure: IP20
►Insulation and Thermal Endurance Class: Class B
►Electrical Strength: No flashover or breakdown when at 2000V/min
►Insulation Resistance: 5M

FEATURES:
►Full-automatic AC voltage stabilizers is our leading product, it is composed of contact type voltage regulator, servomotor and automatic control circuit.
►This series of voltage stabilizers possesses visible advantages such as elegant appearance, compact design, light weight, high efficiency, no distortion of output waveform, complete protection function.
►This series of voltage stabilizers is suitable for areas where power grid fluctuates frequently or changes greatly along the season, it can be widely applied to industry, scientific research, medical service, school, communication, household appliance.
►It provides any loads with quality power supply to ensure normal running of electric equipment.

FREQUENTLY ASKED QUESTIONS:
►Q: Kaya ba ng AVR Welding Machine 300 Amper inverter?
►A: Depende sa KW capacity ng 300amp nya na welding. Same din sa generator atleast x3 ng rated capacity.
