BUILDMATE Milescraft Euro Hinge Jig Installation Tool Kit for Cabinet Door Concealed Hinges EuroHingeJig #1342

BUILDMATE Milescraft Euro Hinge Jig Installation Tool Kit for Cabinet Door Concealed Hinges EuroHingeJig #1342

SPECIFICATION:
►Model: 1342
►Edge Offsets: 2.5mm, 3mm, 4mm, 5mm, 6mm, 7mm
►Locator Pin Offsets: 3”, 4”
►Drill Bit: 35mm EuroHinge Boring Bit
►Shank: 3/8″ Round
►Depth Stop: 3/8″ Split
►Depth Settings: 12.7mm, 13mm

INCLUDE:
►Hinge Marking Guide
►1/16” Pilot bit
►3mm Allen Wrench

FEATURES:
►Two edge alignment knobs position the cup hole from the edge of the door, while the edge locator pin sets the distance from the top/bottom
►The drill guide with metal bushing locks into the jig and creates a perfectly straight hinge cup hole
►Guide bushings built into the body of the jig let you pre-drill pilot holes in four common locations, making sure hinges are straight and the door closes true
►Easily set your cup hole depth on the included 35mm high-speed steel bit using the built-in depth setting fixtures
►The hinge marking guide detaches from the bottom of the jig and allows you to transfer and mark centerlines and hinge location to cabinet wall or frame
