POWERHOUSE Turbomaxx Synergic Inverter Type 250A - 550A Industrial Welding Machine - PHWM

Description

BUILDMATE Powerhouse Turbomaxx Synergic Inverter Type 250A - 550A Industrial Grade Welding Machine Turbomaxx Plus Series - PHWM

AVAILABLE IN:
►250A - MMA250AMP
►350A - MMA350AMP
►550A - MMA550AMP

SPECIFICATION:
►Model: MMA250AMP
►Current: 10-250A
►Power Voltage: 220V
►Frequency: 60Hz
►Max. Input Power: 7KVA
►Efficiency: 85%
►Max. No-load Voltage: 65V
►Duty Cycle: 60%
►Usable Electrodes: 1.6 - 4.0mm
►Insulation Class: F
►Protection Degree: IP21S
►Measurement: 365 x 230 x 280mm

SPECIFICATION:
►Model: MMA350AMP
►Power Voltage: 220V
►Frequency: 60Hz
►Max. Input Power: 9KVA
►Efficiency: 85%
►Max. No-load Voltage: 75V
►Current: 20-350A
►Duty Cycle: 60%
►Usable Electrodes: 1.6 - 4.0mm
►Insulation Class: F
►Protection Degree: IP21S
►Measurement: 415 x 235 x 335mm

SPECIFICATION:
►Model: MMA550AMP
►Power Voltage: 220V
►Frequency: 60Hz
►Max. Input Power: 12KVA
►Efficiency: 85%
►Max. No-load Voltage: 75V
►Current: 20-550A
►Duty Cycle: 60%
►Usable Electrodes: 1.6 - 5.0mm
►Insulation Class: F
►Protection Degree: IP21S
►Measurement: 495 x 235 x 335mm
